Drillmec 12T1600 Triplex Mud Pump Parts
JinGao Petro Provide Drillmec 12T1600 Triplex Mud Pump Parts
| DRILLMEC 12T1600 FLUID END MODULE & ACCESSORIES | |||||
| ITEM # | DRILLMEC PART # | MISSION PART # | DESCRIPTION | QTY PER PUMP | AVAILABLE |
| 1 | 40390797 | DRILLMEC OEM DRAIWINGS | VALVE HEAD | 6 | OK |
| 2 | 40390798 | DRILLMEC OEM DRAIWINGS | VALVE SEAT | 6 | OK |
| 3 | RI40390796-03 | DRILLMEC OEM DRAIWINGS | SPRING | 6 | OK |
| 4 | 40390797-01 | DRILLMEC OEM DRAIWINGS | INSERT | 6 | OK |
| 5 | 01917638 | DRILLMEC OEM DRAIWINGS | LINER 4-1/2" | 3 | OK |
| 6 | 01917639 | DRILLMEC OEM DRAIWINGS | LINER 5" | 3 | OK |
| 7 | 01917446 | DRILLMEC OEM DRAIWINGS | LINER 5-1/2" | 3 | OK |
| 8 | 01917431 | DRILLMEC OEM DRAIWINGS | LINER 6" | 3 | OK |
| 9 | 01917447 | DRILLMEC OEM DRAIWINGS | LINER 6-1/4" | 3 | OK |
| 10 | 01917448 | DRILLMEC OEM DRAIWINGS | LINER 6-1/2" | 3 | OK |
| 11 | 01917449 | DRILLMEC OEM DRAIWINGS | LINER 6-3/4" | 3 | OK |
| 12 | 01917450 | DRILLMEC OEM DRAIWINGS | LINER 7" | 3 | OK |
| 13 | 01917451 | DRILLMEC OEM DRAIWINGS | LINER 7-1/4" | 3 | OK |
| 14 | 01917452 | DRILLMEC OEM DRAIWINGS | LINER 7-1/2" | 3 | OK |
| 15 | 01912152 | DRILLMEC OEM DRAIWINGS | 4-1/2" PISTON | 3 | OK |
| 16 | 01912153 | DRILLMEC OEM DRAIWINGS | 5" PISTON | 3 | OK |
| 17 | 01912154 | DRILLMEC OEM DRAIWINGS | 5-1/2' PISTON | 3 | OK |
| 18 | 01912163 | DRILLMEC OEM DRAIWINGS | 6" PISTON | 3 | OK |
| 19 | 01912278 | DRILLMEC OEM DRAIWINGS | 6-1/4" PISTON | 3 | OK |
| 20 | 01912149 | DRILLMEC OEM DRAIWINGS | 6-1/2" PISTON | 3 | OK |
| 21 | 01917130 | DRILLMEC OEM DRAIWINGS | 6-3/4" PISTON | 3 | OK |
| 22 | 01912155 | DRILLMEC OEM DRAIWINGS | 7" PISTON | 3 | OK |
| 23 | 01912164 | DRILLMEC OEM DRAIWINGS | 7-1/4" PISTON | 3 | OK |
| 24 | 01912148 | DRILLMEC OEM DRAIWINGS | 7-1/2" PISTON | 3 | OK |
| 25 | 01917364 | DRILLMEC OEM DRAIWINGS | SUCTION MODULE | 3 | OK |
| 26 | 01917365 | DRILLMEC OEM DRAIWINGS | DELIVERY MODULE | 3 | OK |
| DRILLMEC 12T1600 POWER END & ACCESSORIES | |||||
| 27 | 01917366 | DRILLMEC OEM DRAIWINGS | SUCTION MANIFOLD | 3 | OK |
| 28 | 01917351 | DRILLMEC OEM DRAIWINGS | CROSSHEAD | 3 | OK |
| 29 | 01917341 | DRILLMEC OEM DRAIWINGS | CONNECTION ROD | 3 | OK |
| 30 | 01917331 | DRILLMEC OEM DRAIWINGS | PINION SHAFT | 1 | OK |
| 31 | 01917340 | DRILLMEC OEM DRAIWINGS | GEAR, BULL | 1 | OK |
| 32 | 01917339 | DRILLMEC OEM DRAIWINGS | CRANKSHAFT | 1 | OK |
| DRILLMEC | 12T1600 5000 PSI SWFE | 7-1/2 x 12 | ||||||||
| LINERS | LINER GASKETS | PISTONS | PISTON REPLACEMENT RUBBERS | |||||||
| SIZE | CERAMIC | SUPREME | RUBBER | URETHANE | BLUE LIGHTNING | GREEN DUO | WHITE LIGHTNING | SUPREME | WHITE LIGHTNING | SUPREME |
| 4" | ||||||||||
| 4 1/4" | ||||||||||
| 4 1/2" | 1540120 | MB44-15 | 1502054 | 12180197 | 12180196 | 15180145 | 15180144 | |||
| 4 3/4" | 1504121 | |||||||||
| 5" | 7466500 | 05466500* | 7923264 | MB50-15 | 1502056 | 12180254 | 12180253 | 15180186 | 15180185 | |
| 5 1/4" | ||||||||||
| 5 1/2" | 7466550 | 05466550* | 7923263 | 7211005 | MB54-15 | 1502058 | 12180338 | 12180337 | 15180228 | 15180227 |
| 5 3/4" | ||||||||||
| 6" | 7466600 | 05466600* | 7923261 | 7211004 | MB60-15 | 1502060 | 12180395 | 12180394 | 15180269 | 15180268 |
| 6 1/4" | 05466625* | 7923283 | 1502061 | 12180493 | 15180285 | 15180284 | ||||
| 6 1/2" | 7466650 | 05466650* | 7923284 | 7211003 | MB64-15 | 1502062 | 12180536 | 12180535 | 15180301 | 15180300 |
| 6 3/4" | ||||||||||
| 7" | 7466700 | 05466700* | 7923285 | 7211002 | MB70-15 | 1502064 | 12180619 | 12180618 | 15180343 | 15180342 |
| 7 1/4" | ||||||||||
| 7 1/2" | ||||||||||
| 7 3/4" | ||||||||||
| 8" | For Bonded White Lightning Pistons add "XT" to Green Duo Part # | |||||||||
| * For HP style liner, add "HP" to end of part no. | ||||||||||
| VALVES, SEATS, SPRINGS & INSERTS | GASKETS | |||||||||
| Series 7 | ROUGHNECK | ROUGHNECK HP | SUPREME | FKN | OEM | OEM URETHANE | L STYLE | L STYLE URETHANE | L STYLE W.L. | |
| VALVE-White Lightning Insert | 9700368 | 9700356 | 60155042 | N/A | Valve Cover | NA | NA | 7207119 | 7211013 | 7213013 |
| VALVE-Urethane Insert | 9700250 | 9700354 | 60155041 | 1560985 | Wear Plate | NA | 1290344 | 7211023 | 7213023 | |
| VALVE-Rubber Insert | 9700293 | N/A | 60155033 | 1560984 | Liner Retention Systems | OEM | MISSION L | |||
| SEAT | 9702539 | 9702539 | 61102505 | 1561440 | Blak-JAK LOK-CEL | 80501100 | 80501100 | |||
| SPRING | 8201684 | 8201684 | 55413421 | 1560702 | Blak-JAK Hydra-Cell | 80502100 | 80502100 | |||
| SPRING-Stainless | 55402945 | Hydra-LOK | 80500100 | 80500100 | ||||||
| INSERT-Urethane | 9705228 | PFO7I | 62400338 | 1560557 | MODULES | OEM | MISSION L | |||
| INSERT-Rubber | 9705244 | N/A | 62400239 | 1560558 | Complete Assembly | NA | FEM12PASSYSWNS | |||
| SEAT PULLER ASSEMBLIES | Discharge Module Studded | NA | FEM12PDISSWNS | |||||||
| Puller Assembly 1 | M 1060 | M 1060 | M 1060 | M 1060 | Suction Module Studded | NA | FEM12PSUCSWNS | |||
| Puller Head | 8401985 | 8401985 | 181235300 | M 1098 | One Piece OEM Style Studded | |||||
| Crosshead Extension Rods, Quick Connect Rods, Self Aligning Rod Assemblies & Piston Rods | ||||||||||
| Crosshead Rod | Quick Connect | Self Aligning Rod Assembly | Rod Nut | Piston Rod | Sub Rod | Pony Rod Baffle | Piston Rod Clamp | Covered Rod Nut | Pony Rod Seal | |
| XM-296 | 2095220 | 5402052 | 1292147 | 1292146 | 1292194 | W/SPRAY | 80701024 | CRN-1 | 1292182 | |
| WO/SPRAY | 5417357 | |||||||||
NATIONAL
14-P- 220
Item |
Part Number |
Description |
Qty per Pump |
| 1 | P-1295240 | Discharge Module Studded, (incl. Items 2-10) | 3 |
| 2 | P-1295241 | Discharge Module, Only | 3 |
| 3 | P-6300320 | Nut, 2“ -8 Hvy. Hex | 18 |
| 4 | P-2408048 | Stud, 2“ -8UNC X22 7/8” | 18 |
| 5 | P-6300180 | Nut, 1 1/8“ Hvy. Hex | 18 |
| 6 | P-2408028 | Stud, 1 1/8“ X 6 3/8”, Discharge to Liner Bushing | 18 |
| 7 | P-6300281 | Nut, 1 3/4“ Hvy. Hex | 18 |
| 8 | P-2408033 | Stud, 1 3/4“ X 21 1/8”, Discharge to Suction | 18 |
| 9 | P-6300240 | Nut, 1 1/2 Hvy. Hex | 36 |
| 10 | P-2408027 | Stud, 1 1/2“ X 7 7/8” Top, Thread Ring | 36 |
| 11 | P-1295243 | Suction Module Studded, (incl. Items 12-14) | 3 |
| 12 | P-1295244 | Suction Module, Only | 3 |
| 13 | P-6300240 | Nut, 1 1/2 Hvy. Hex | 36 |
| 14 | P-2408049 | Stud, 1 1/2“ X 9 7/8” Top, Thread Ring | 36 |
| 15 | P-1295165 | Bushing, Liner | 3 |
| 16 | P-1295174 | Seal Retainer | 6 |
| 17 | P-1295172 | Valve Cover | 6 |
| 18 | Non | Screw, Wedge Adjusting | 6 |
| 19 | Non | Nut, Wedge Adjusting | 6 |
| 20 | Non | Washer, Wedge Adjusting Screw | 6 |
| 21 | P-1295176 | Ring, Threaded | 6 |
| 22 | Non | Wedge Assembly | 6 |
| 23 | P-1540163 | Gasket, Valve Cover | 6 |
| 24 | P-1292140 | Holder, Valve Guide Insert | 6 |
| 25 | P-1292141 | Insert, Valve Guide | 6 |
| 26 | P-6571620 | Pin Dowell | 6 |
| 27 | P-1295266 | Plate, Wear | 3 |
| 28 | P-1295252 | Connector, Discharge | 2 |
| 29 | P-7000-307-11 | Screw Hex Head | 16 |
| 30 | P-7619050 | Washer, Lock | 16 |
| 31 | P-1295253 | Adapter, Discharge Connector | 2 |
| 32 | P-2410031-440 | Packing, Rectangular | 2 |
| 33 | P-2410031-438 | Packing, Rectangular | 4 |
| 34 | P-1295167 | Clamp, Liner | 3 |
| 35 | P-7000491-10 | Screw 7/8 X 4 1/2“ Hex Hd. w/ Lock Washer | 6 |
| 36 | P-6309140 | Nut, 7/8“ Lock Type | 6 |
| 37 | P-1292169 | Pin, Liner Clamp | 3 |
| 38 | P-1295168 | Connector, Liner Clamp | 3 |
| 39 | P-2408015 | Stud 1 1/2“ x 7 1/2” | 16 |
| 40 | P-6300240 | Nut, 1 1/2“ Hvy. Hex | 16 |
